Specially developed for lifting ISO and EURO pallets in Very Narrow Aisles to over 14 metres of lift Heavy Duty Double-Deck 2.5 tonne articulation unit Full 2000kgs at 600mm load centres to 5 metres Latest generation Zapi digital drive technology for no motor maintenance costs Narrowest ‘True™ Radius’ chassis allows fast efficient pallet put away and optimum travel speed in the aisle Unique Heavy Duty Fixed Mast tilting carriage design for unbeatable high-level stability Integrated Side shifting and tilting forks design means costly special super flat floors are not required Unique ‘VISION’ twin post operators overhead guard exceeds CE/US load test standards High Definition LCD CCTV Operator Vision System is standard fitment. Programmable lift height selector can be added Range chassis widths available in 1350mm,1450mm and 1500mm for optimum lift performance at all lift heights Heavy-duty 2.5 tonne articulation unit provides ultra-reliable long term usage Independent digital power steering motor for maximum energy saving and eliminates ‘kickback’ Ground-level picking and storage locations can be accessed during normal operations by other MHE

Flexi MAX 22/25 features chassis options to provide extra lift heights and load capacities

Flexi MAX 22/25 lifts heights to over 15.0m/590″.
Heavy-duty fixed space German steel frame lift beam mast for unbeatable high-level stability.
Tilting and side shifting fork carriage (Kaup) means special flat floors not required.
HIVIS rollover operators guard exceeds all EU/US safety standards.
CCTV/LCD HiDEF integrated operator vision system.
Integrated Laser lift height selector system.
Heavy-duty 2.5t/5,000lbs articulation design.
Four compact chassis widths 1.25m/50″, 1.35m/53″, 1.4m/55″ and 1.5m/60″ for optimum aisle way performance depending on load weight and lift.
Independent digital power steering motor for maximum energy saving and no kickback – 20% more pallet moves.
End of aisle transfer in only 3 metre aisle adds 10% more pallet location compared to Man Up Combi.
Three ‘brushless’ digital electric motors for long battery life and ultra-low servicing costs.
Adds 30% more ground level picking locations, compared to moving mast reach trucks.
Consistant 3° tilt at all lift heights.

NOMINAL CAPACITY

2500kg

MAXIMUM LIFT HEIGHT

14.5m

AISLE WIDTH

2.0m - 2.2m

CHASSIS WIDTH

1250mm - 1500mm

Engineered for high lift capability
Four chassis widths, plus elastic rubber treaded rear tyres, delivers excellent load rating and stability up to 15.0m/590″.

Heavy-duty fixed mast
Heavy-duty mast sections fixed in a double-deck front frame give maximum load stability.

High-quality tilting carriage
Integrated tilting and side shifting fork carriage developed to eliminate mast deflection at high lifts. Lift mast stays vertical, only the forks and load move.

High definition LCD CCTV system
Allows operator to stack safely to up to 15.0m/590″ with minimum fatigue, integrated programmable shelf height selector.

More Information

Specially developed for lifting ISO and EURO pallets in Very Narrow Aisles to over 14 metres of lift
Heavy Duty Double-Deck 2.5 tonne articulation unit
Full 2000kgs at 600mm load centres to 5 metres
Latest generation Zapi digital drive technology for no motor maintenance costs
Narrowest ‘True™ Radius’ chassis allows fast efficient pallet put away and optimum travel speed in the aisle
Unique Heavy Duty Fixed Mast tilting carriage design for unbeatable high-level stability
Integrated Side shifting and tilting forks design means costly special super flat floors are not required
Unique ‘VISION’ twin post operators overhead guard exceeds CE/US load test standards
High Definition LCD CCTV Operator Vision System is standard fitment. Programmable lift height selector can be added
Range chassis widths available in 1350mm,1450mm and 1500mm for optimum lift performance at all lift heights
Heavy-duty 2.5 tonne articulation unit provides ultra-reliable long term usage
Independent digital power steering motor for maximum energy saving and eliminates ‘kickback’
Ground-level picking and storage locations can be accessed during normal operations by other MHE

Interested in the :

Flexi MAX 22/25

Flexi MAX 22/25

Flexi MAX 22/25 features chassis options to provide extra lift heights and load capacities

NOMINAL CAPACITY

2500kg

MAXIMUM LIFT HEIGHT

14.5m

AISLE WIDTH

2.0m - 2.2m

CHASSIS WIDTH

1250mm - 1500mm
